Alto Truemix 800 FX 8-Channel Analogue Mixer W/ USB

The Alto Professional TrueMix 800 FX is a compact audio mixer that comes with built-in DSP effects and all the necessary features for various applications such as home recording, live streaming, podcasting, or performing. It boasts 16 effects, including chorus, flange, high-quality delays, and reverbs, and also has a Bluetooth channel that allows you to stream easily from your devices.

With the use of mix-minus technology, this Bluetooth channel even supports feedback-free phone pairing, which is a unique feature of the TrueMix Series. The mixer has eight analogue inputs that come with high-headroom circuitry to minimize noise and clipping in your signal.

The four Mic Input Channels feature XLR inputs that are great for connecting dynamic mics or condenser mics with 48v phantom power, as well as balanced ¼” line inputs for instruments and other line-level signals. In addition, the mixer has two Stereo Input Channels, each with dual balanced ¼” TRS inputs that are perfect for line-level audio sources.

All channels have a two-band EQ with colour-coded knobs for easy sound customization, even in low-light situations. The TrueMix 800 FX is also designed for quick connectivity to your computer, with plug-and-play capability on both Windows and macOS.

Furthermore, the mixer comes with extra knob caps so you can customize its look. Overall, the TrueMix 800 FX is an excellent choice for those who require a feature-packed, compact audio mixer for on-the-go use.

Key Features:

• USB I/O for audio playback and stereo recording
• Dedicated Bluetooth channel with mix-minus return for feedback-free phone pairing
• Four headphone outputs with independent volume control
• 16 built-in Alesis multi-fx with dedicated return channel
• 1/4” Main, Tape, and AUX outputs
• Four mic input channels with phantom power and balanced line inputs
• Two stereo input channels with balanced 1/4” TRS jacks
• Two-band EQ on all channels
• 2-track inputs w/ assignable routing: main mix or headphone out
• Eight-segment LED VU meter for precise level monitoring
• Extra knob caps are included in the box for added customisation

Alto Truemix 800 FX 8-Channel Analogue Mixer w/ USB Specifications:

• Frequency Response: All inputs: 20 Hz – 22 kHz (±1 dB)
• THD+N (Total Harmonic Distortion): All inputs: < 0.05% (@ 4 dBu, 1 kHz)
• Gain Range Mic inputs (Channels 1 4): 0 – +48 dB, Line inputs (Channels 1-4): 15 – +33 dB, Line inputs (Channels 5-6): 20 – +20 dB, All inputs: +22 dBu max
• Max Voltage Gain: 68 dB (Mic Input to Main, 2TK, EFX, Control Room, Headphone Outputs), 40 dB Line Input to Main, 2TK, EFX, Control Room, Headphone Outputs, 58 dB Mic Input to MON Output, 30 dB (Line Input to MON Output), 10 dB (RETURN Inputs to MON Output), 20 dB (2TK/USB/EFX RETURN/Bluetooth to Main, 2TK, Control Room, Headphone Outputs)
• SNR (Signal to Noise ratio): All inputs: > 110 dBu
• Phantom Power: +45 ~ +49V with switch control
• Impedance Mic inputs: 3.9 kO, All other inputs: > 10 kO, Aux outputs: 1 kO, 2TK outputs: 1 kO, All outputs: 120 O
• Equalization High: ±15 dB @ 12 kHz, Low: ±15 dB @ 80 Hz
• Bluetooth Profile: A2DP, Module: Bluetooth 5.0, Operating Frequency: 2402 MHz – 2480 MHz, Range: 100 ft. / 30.5 m
• USB Audio Interface Version: 2.0, Resolution: 16 bit, DAC Sampling: 32, 44.1, 48 kHz, ADC Sampling: 8, 11.025, 16, 22.05, 32, 44.1, 48 kHz
• Connectors: (6) 1/4” (6.35 mm) TRS outputs, (6) 1/4” (6.35 mm) TRS stereo L/R inputs, (4) 1/4″ (6.35 mm) TRS headphone outputs, (4) 1/4″ (6.35 mm) TRS mono inputs, (1) Standard RCA L/R input, (1) Standard RCA L/R output, (4) XLR inputs, (1) USB type B input, (1) DC power input
• Controls: (1) Power switch, (15) volume control knobs (1 per input, 1 return, 1 EFX return, 1 2
• track/USB in, 4 headphone outs, 1 Bluetooth, 1 main), (6) Stereo pan control knobs (1 per input), (6) Mon volume control knobs (1 per input), (6) EQ Low control knobs (1 per input), (6) EQ Hi control knobs (1 per input), (6) Gain control knobs (1 per input), (4) Buttons (1 EFX mute, 1 Bluetooth, 2 Source Select), (1) Horizontal sliding switch
• Indicators: (1) Power LED, (6) Peak LEDs, (1) Phantom LED, (16) Main Out Meter LEDs, (1) Bluetooth LED
• DSP Engine: A/D and D/A converters: 24-bit. DSP Resolution: 20 bit. Effects: Reverbs: Room, Hall, Plate, Tape, Spring. Delay: (max 650ms). Modulation: Chorus, Flanger. Combo: Delay+Reverb, Chorus+Reverb, Flanger+Reverb. Presets: 16
• Main Mix Main output: (2) 1/4″ (6.35 mm) balanced TRS, +22 dBu max output, 2TK output: (2) unbalanced RCA, +22 dBu max output. Headphone output: (1) stereo 1/4″ (6.35 mm) TRS, 200 mW @ 32 O
• Power: Connection: DC. Voltage: 18V, 1.2A. Consumption: 21.6 W
• Dimensions (width x depth x height): 12.0” x 9.4” x 3.1” / 305 x 238.5 x 79 mm
• Weight 4.5 lbs / 2.04 kg
