IK Multimedia IRig Pro DUO I/O

Always achieve the most professional-sounding recordings wherever you are with the IK Multimedia iRig Pro DUO I/O, an impressively compact 2-channel audio/MIDI interface for recording with iPhone, iPad, Android devices and Mac/PC.

A perfectly crafted selection for podcasters and musicians where full studio setups aren’t an option or practical, the iRig Pro DUO I/O comes with numerous input sources that include microphones, MIDI controllers, a line-level plus high impedance instruments such as guitars, basses and much more.

With updated features taken from the highly appraised IK Rig Pro Duo, the Pro DUO I/O boasts updated mic preamps that feature improved gain and a handy USB-C cable to work with the most recent devices.

Not only that but the onboard PC drivers guarantee enhanced functionality when used with laptops and tablets, along with volume controls that come with level indicators for the perfect recording every time.

Key Features:

Two-channel audio/MIDI interface
Record anywhere thanks to battery and bus power
Seamless integration with iOS, Android and PC applications
Free access to a wide range of IK software, apps, and in-app material

IK Multimedia iRig Pro Duo I/O Specifications:

Microphone input:

• Microphone Input: 2x balanced, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground
• Microphone Input Level: from 6 mVpp to 1.4 Vpp
• Microphone Input Impedance: approx 2 kOhms
• Gain Range: 48 dB
• Phantom Power: +48V ± 4V
• Frequency Response:from 5 Hz to 21 kHz (-3dB) Gain @ min, from 30 Hz to 21 kHz (-3dB) Gain @ max
• Input Noise: -103 dB(A) Gain @ min, -86 dB(A) Gain @ max

Instrument Input:

• Instrument Input: 2x unbalanced, Hi-Z, TS 1/4” Jack, Tip: signal / Shield: ground
• Instrument Input Level: from 30 mVpp to 6.9 Vpp
• Instrument Input Impedance: 1 MOhms
• Gain Range: 27 dB
• Frequency Response: from 2 Hz to 21 kHz (-3dB) Gain @ min, from 5 Hz to 21 kHz (-3dB) Gain @ max
• Input Noise: -104 dB(A) Gain @ min, -102 dB(A) Gain @ max

Line Output:

• Line Outputs: 2x balanced, TRS 1/4” Jack, Tip: hot / Ring: cold / Shield: ground
• Floating Balanced Outputs: automatic level compensation when working in unbalanced mode
• Maximum Output Level: +16 dBu into 600 Ohms balanced load
• Frequency Response: from 10 Hz to 21 kHz (-3dB)
• Output Dynamic Range: 106 dB(A)
• Output Impedance: 150 Ohms balanced

Common:

• AD and DA Resolution: 24-bit
• Sampling Rate: 44.1 kHz and 48 kHz
• Power: USB bus power, battery power (2xAA – included), or DC power supply (9VDC, from 500mA up, positive outside – not included)
• Metering: Multicolor LED
• Size: 75mm x 127mm x 37mm
• Weight: 197.2g (batteries excluded)
• Battery Life:
• Recording – Max load*: 3 hours, 30 minutes (NiMH rechargeable); 45 minutes (Alkaline)
• Playback – Min load**: 10 hours (NiMH rechargeable); 3 hours (Alkaline)
