LD Systems ICOA 12 A 12 Active PA Speaker

Highly versatile and powerful, the LD Systems ICOA 12 A 12″ Active PA Speaker is a powerhouse of sound and versatility that sets the standard for professional audio performance. Designed to deliver phenomenal sound quality and unmatched flexibility, this speaker is a game-changer for live events, performances, and installations.

With its unique coaxial woofer design, the ICOA 12 A ensures an immersive audio experience like no other. The combination of a 12” woofer and a coaxially-mounted compression driver delivers crystal-clear sound reproduction with a remarkable bass response. Whether you’re pumping up the crowd at a concert or delivering a captivating presentation, this speaker will make your audio shine.

Key Features:

• Advanced Design – Thanks to the precisely-calibrated DynX DSP algorithms, your sound is in the hands of advanced technology. This intelligent processing ensures that every note, every beat, and every word is delivered with precision and accuracy. Experience the full potential of your audio with a speaker that truly does justice to your sound.
• Built to Last – Built to last and engineered with LD Systems’ renowned craftsmanship, the ICOA 12 A ensures years of reliable performance. Every component is meticulously designed and tested to meet the highest standards, giving you the peace of mind that your sound will be consistent and exceptional, show after show.
• Multiple Placement Options – Versatility is at the core of the ICOA series. The rotating BEM-optimized CD horn allows you to position the speaker vertically or horizontally, adapting to any stage or venue configuration. The dual-tilt pole receptacle and six M10 rigging points provide you with multiple mounting and installation options, giving you the flexibility to optimize your sound setup for any application.

LD Systems ICOA 12 A 12 Active PA Speaker Specifications:

• Product Type: PA loudspeaker
• Type: Active
• Low/Mid Driver: 12” custom-made
• Size: 304.8mm
• Magnet: Ferrite
• Horn: BEM-optimised CD horn
• HF Driver: 1” custom-made
• Size: 25.4mm
• Magnet: Ferrite
• Voice Coil: 1” / 25.4mm
• Dispersion: 90° x 50° (H x V)
• Amplifier: Class-D
• Power: 300W (RMS) / 1200W (peak)
• Frequency Response: 50Hz – 20kHz
• Crossover Frequency: 2kHz
• Maximum SPL: 126dB (peak)
• Protection Circuits: Multiband limiter, Over voltage, Over current, Thermal overload
• Controls: 2 x gain, ON/OFF switch, Rotary/push encoder
• Indicators: LC display
• Min/Line Inputs: 2 x XLR-1/4” combo jack connectors
• Line Inputs: 1 x 3.5mm TRS connector
• Line Outputs: 1 x XLR
• Cabinet:
• Material: Polypropylene
• Construction: Bass-reflex
• Tripod Flange: 36mm flange, 5° or 0° (dual-tilt)
• Monitor Angle: 55°
• Handles: 4
• Rigging Points: 6 x M10
• Operating Voltage: SMPS 100-240VAC, 50-60Hz
• Power Consumption: 150W
• Fuse: T4AL 250V
• Dimensions: 375mm x 635mm x 396mm (W x H x D)
• Weight: 19.95kg
