Mackie ONYX 24 24-Channel Analogue Mixer With Multi-Track USB

Offering a 24 channel recording mixer to capture high-quality and crisp audio in the studio and on the stage

Premium 24-Channel Mixer

Offering twenty four channels, eighteen award-winning high-gain mic preamps, 4-Bit/96kHz multitrack recording, and ultra-low noise analogue circuitry the Mackie ONYX 24 24-Channel Analog Mixer with Multi-Track USB offers clear and crisp recorded audio.

Mackie ONYX 24 24-Channel Analogue Mixer with Multi-Track USB Key Features:

• Legendary performance from award-winning mic preamps and analogue circuitry
• Record every channel straight to your Mac/PC via USB
• Unrivalled control from Studio Command, FX, and, and three-band EQ
• Maximum performance for years to come with a heavy-duty construction

Premium Award-Winning Mic Preamps

The Oynx 24 offers simple controls to get the best out of your audio. With eighteen award-winning high-gain mic preamps you get a low-noise solution and with 60db of gain tons of headroom. Crystal clear quality sound.

Perkins EQ

The ‘British’ style Perkins 3-Band EQ and simple rotary encoders deliver that legendary 60’s and 70’s sound with that sweepable midrange.

What’s more, you can add colour and texture to the inputs with the custom-built effects engine.

24-Bit/96kHz Multitrack Recording

Connect to your Mac or PC and get full multitrack recording capabilities into your chosen DAW.

You also get Pro Tools or Waveform OEM software bundles included. Get recording, straight out of the box.

High-Quality Effects

You can save all the effects to 6 users presets, which can be recalled easily and quickly. Reverb, chorus, and everything else is there with the touch of the button.

Mackie ONYX 24 24-Channel Analog Mixer with Multi-Track USB Features:

• Flawless sound from eighteen award-winning Onyx mic preamps with 60dB of gain
• Studio-quality audio on stage thanks to analogue circuitry
• Flexible routing from analogue/USB channel strips
• Achieve classic 60s and 70s sound from a ‘British style’ EQ with sweepable midrange
• Take your sound to the next level with the digital effect engine, including reverb, chorus, and more
• Record straight to your Mac/PC via USB with 96kHz/24-bit multi-track capabilities
• Direct to SD card recording and playback in stereo
• Easily assign your channels to 4-track USB return (2 stereo pairs)
• Send your main mix to USB at the touch of a button
• A user-friendly navigation system gives unrestricted access to FX parameters, SD recording, and playback
• Find files quickly thanks to the built-in display and dedicated search buttons
• Recall your favourite sounds from 6 user FX presets
• Sculpt your sound with precision thanks to adjustable parameters and dedicated 3-band EQ
• Stream music wirelessly via Bluetooth connectivity
• Streamed audio can be routed to an Aux Send and the Main Mix
• Pristine sound for instruments via Hi-Z switches
• Tame your bottom end with 100Hz low-cut filters on all mic channels
• Full range of connectivity, including stereo line inputs, Aux/Monitor output, control room outputs, and headphone out
• Monitor your mixer’s performance with 12-segment stereo meters
• Monitor overload with dedicated indicators on all channels
• Footswitch input for FX Mute
• Easy to use in dark environments thanks to a backlit display
• ’Built-like-a-tank’ steel chassis for maximum performance
• Get recording straight out of the box with Pro Tools and Waveform OEM software and plugin bundles

Mackie ONYX 24 24-Channel Analog Mixer with Multi-Track USB Specifications:

Inputs

• Input channels: 24 total, 14 x mono mic/line, 4 x stereo/mic line, 1 x stereo line
• Mic preamp type: Onyx Mic Pre w/ up to 60dB of gain
• 48V phantom power: Global, switchable
• 100Hz channel low cut: Switchable per channel
• Channel EQ: Perkins “British style” 3-band EQ with sweepable midrange and On/O switch
• Channel inserts: Ch. 11–14

Outputs

• Aux sends: 2 + FX Send
• Bluetooth and stereo 1/8″: Ch. 23/24
• Main outputs: L/R TRS and XLR
• Main meters: 12-Segment LED
• Channel solo: AFL / PFL

Other

• Level controls: Knobs
• Internal FX: Adjustable Delay, Reverb, Chorus, and more
• Built-in display: Full-Color Display and Single-Knob Interface. Adjust FX parameters, recall presets, manage and play recordings/music
• USB recording: 96 kHz / 24-Bit 14×4 on Mac/PC
• SD card recording: 96 kHz / 24-Bit 2×2

Construction

• Power supply: Internal Universal 100 – 240 VAC
• Weight: 9.7 kg
• Dimensions: 639 × 356 × 136 mm
• Rackmount: With Optional Rackmount Kit
• Product code: 2051993-03
