This lightweight full range personal PA system features two 5″ Eminence speakers with a high frequency driver, multiple inputs, phanto power, and balanced XLR outputs.
Powerwerks Tower PA Specifications
- Output Power: 50W
- Accepted Inputs: Channels 1 and 2: Mic XLR, Line level 1/4″ Un-balanced
- Hum and Noise: -65 dB: Residual noise, all level controls at 0% (minimum), -48 dB Nominal system noise, all level controls at 50%
- System Gain (Measurements made at 1 kHz): +70 dB: Mic to speaker output (Channel 1 and 2), +56 dB: Line to speaker output (Channel 1 and 2), +42 dB AUX IN to speaker output
- Channel EQ (High, low): 4 kHz and above, 800 Hz and below
- Powerlink (In and OUT): Both jacks accept a balanced input and sends a pre-master volume output mix of channels. Recommended use. Linking two PW505BT units together
- Subwoofer Out: Line out, 200 Hz-150 Hz
- Phantom Power: +15, Mic inputs (Channel 1 and 2)
- Power Requirements: Europe: 230VAC/50 Hz, 80 W Nominal, UK: 230VAC/50 Hz, 80 W Nominal
- Speakers: 2 x 5″, 25 W 16 Ohm each
- Horn: 3.5″ piezo driver
- Power Capacity: 50 W, RMS
- Frequency Response:60 Hz – 20 kHz, Full range (subwoofer jack not used), 150 Hz – 20 kHz, Crossover active ( 1/4″ mono plug in subwoofer jack )
- Nominal Impedance: Not designed for external speakers
- Bluetooth Module Features: Bluetooth 3.0+EDR compliant Typical +2 dBm Class 2 output power Audio DAC 94 dB SNR A2DP profile support
- Top Hat Speaker Connector: 35mm / 1 3/8″ diameter
- Dimensions: 7.2″ W x 18.8″ H x 7.3″ D, 192mm W x 478mm H x 185mm D
- Weight: 16 lbs, 7.2 kg
