PreSonus IOSTATION 24C Audio Control Surface

The new Presonus IOStation 24C carries the DNA of the original Presonus Faderport but with some bold new features. Now featuring a 2×2, 24-bit USB Audio Interface built-in, the IOStation is the ultimate mobile mixing tool for engineers on the move.

Your New Mobile Mixing Tool

As a solo artist, you’ll know that you need more than just creativity to realise your vision – you also need to be a producer and audio engineer.

The ioStation 24c has been designed to give you all of the tools you need to combine these diverse roles, and is hosed in an ergonomic, compact package that can fit into any home studio.

PreSonus IOSTATION 24C 2×2 USB-C Audio Interface Highlights

• USB-C compatible 24-bit/192kHz audio interface
• Touch-sensitive motorised fader and intuitive navigation controls allow you to control your favourite DAW with ease
• Conpact and ergonomic design allows the Iostation to fit into any studio, bedroom, or backpack
• 2 mic/instrument/line inputs with XMAX mic preamps
• 2 balanced 1/4″ TRS main outputs
• Simultaneous I/O up to 2 inputs and 2 outputs
• Mixer knob for low-latency direct input monitoring
• 1.25″ headphone output with independent level control
• USB 2.0 connectivity, compatible with macOS and Windows
• Includes Studio One Artist recording and production software, and over 6GB of additional loops and sample content

Superior Front-End For Superior Results

With it’s high-quality digital furthers and transparent preamps, the ioStation 24 allows you to create both superior recordings and awesome listening experiences.

The preamps are PreSonus’s very own acclaimed XMAX Class A Mic pre’s, and deliver aa high headroom, with deep lows, shared smooth highs, and a rich overall sound.

In addition to this, the high-quality converters provide 115 dB of dynamic range of capture complex musical harmonics smoothly and naturally, resulting in clear, consistent audio to make mixing easier.

Work Smarter

Featuring elements from the award-winning FaderPort-series controllers, the ioStation 24c offers an intuitive mixing experience.

In addition to the streamlined workflow, you get support for the Mackie Control and HUI protocols, allowing you to easily control Pro Tools, Logic Pro X, Cubase, Ableton Live, and more, with no driver installation necessary.

Includes World-Class Recording Software

Presonus’s ioStation 24 will not only seamllessly integrate with Studio One Artist recording software: it actually comes complete with a copy of it!

Studio One Artist is compatible with both macOS and Windows operating systems (see below for exact specifications needed), allowing you to use the ioStation 24 to compose, record, and produce with ease.

Your Studio Assistant

With its unique Session Navigator, the ioStation 24c is like your hard-working, caffeine-fueled assistant engineer, giving you easy access to 8 fundamental functions for incredible levels of flexibility.

Each of the controls is labeled accordingly, and allows you to do everything you need during the pre-production, post-production, and recording stages of the creative process.

One Is The Happiest Number

Whether you’re a complete newcomer to the audio production scene, or are looking to streamline your recording rig, the ioStation 24c audio interface and production controller is here to offer clean, ultra-high-definition sound and professional mixing tools.

Contact our Online Sales Team directly if you’d like to query the availability of the iOstation 24c.

Computer System Requirements

Mac

• macOS 10.11 or higher (64-bit only)
• Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
• 4 GB RAM (8 GB or more recommended)

Windows

• Windows 7 x64 SP1 + platform update, Windows 8.1 x64, Windows 10 x64
• Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
• 4 GB RAM (8 GB or more recommended)

Mac and Windows Systems

• USB-C or USB-A 2.0 port compatibility
• 32 GB hard disk space
• PreSonus Universal Control 2.0 or higher
• Monitor with 1366×768 resolution (high-dpi monitor recommended)
• Multitouch-enabled monitor required for touch operation

PreSonus IOSTATION 24C 2×2 USB-C Audio Interface Specs

Microphone Preamp

• Type: XLR Female (via Combo), Balanced
• Maximum Input Level: +16 dBu (Balanced, min. gain)
• Gain Control Range: 80 dB
• Frequency Response: 20 Hz to 20 kHz (±0.15 dB, unity gain, 48 kHz)
• Dynamic Range: > 107 dB (A-wtd, min. gain)
• Total Harmonic Distortion: < 0.007% (1 kHz, min. gain)
• EIN: < -128 dBu (max gain, 40 , 22 kHz BW, A-wtd)
• Input Impedance: 1.6 k
• Phantom Power: +48V, > 8 mA per input

Instrument Inputs

• Type: 1/4″ TS Female (via Combo), Unbalanced
• Maximum Input Level: +15 dBu (Unbalanced, min. gain)
• Gain Control Range: 80 dB
• Frequency Response: 20 Hz to 20 kHz (±0.2 dB, unity gain, 48 kHz)
• Dynamic Range: > 110 dB (A-wtd, min. gain)
• Total Harmonic Distortion: < 0.012% (1kHz, -1 dBFS, min. gain)
• Input Impedance: > 1 M

Line Inputs

• Type: 1/4″ TRS Female (via Combo), Balanced
• Maximum Input Level: + 22 dBu (Balanced, min. gain)
• Frequency Response: 20 Hz to 20 kHz (±0.05 dB, unity gain, 48 kHz)
• Dynamic Range: > 114 dB (A-wtd, min. gain)
• Total Harmonic Distortion: < 0.007% (1 kHz, -1 dBFS, min. gain)
• Input Impedance: 10 kOhm

Main and Line Outputs

• Type: 1/4″ TRS Female, impedance balanced
• Maximum Output Level: +18 dBu (Balanced)
• Frequency Response: 20 Hz to 20 kHz (±0.2 dB, unity gain, 48 kHz)
• Dynamic Range: > 109 dB (A-wtd)
• Total Harmonic Distortion: < 0.005% (1 kHz, +4 dBu)

Headphone Outputs

• Type: 1/4″ TRS Female, Stereo, Unbalanced
• Maximum Output Level: 150 mW/channel (56 load)
• Frequency Response: 20 Hz to 20 kHz (±0.2 dB, 56 load, 48 kHz)
• Dynamic Range: > 107 dB (A-wtd)
• Total Harmonic Distortion: < 0.02% (1 kHz, -1 dBFS, no load)
• Headphone Impedance (working range): 32 to 300

Digital Audio

• Connection Type: USB 2.0 over USB-C Compatible Connection
• ADC Dynamic Range: 115 dB (A-wtd)
• DAC Dynamic Range: 115 dB (A-wtd)
• Bit Depth: 24 bits
• Internally Supported Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz

Clock

• Jitter: < 70 ps RMS (20 Hz – 20 kHz)
• Jitter Attenuation: > 60 dB (1 ns in => 1 ps out)

Power

• 12 VDC, 1.2A, external power supply

Physical

• Height: 2.4″ (61 mm)
• Depth: 6.8″ (172 mm)
• Width: 9.6″ (244 mm)
• Weight: 2.2 lbs (1 kg)
