PreSonus Revelator Io24 USB-C Audio Interface

The latest in PreSonus’ powerful line of USB-C Compatible Audio Interfaces, the versatile Revelator io24 is perfect for anything from streaming to podcasting to music production to studio recording!

All-In-One Multimedia Interface For The Modern Creative

Capable of delivering polished and professional studio-quality audio for your stream, podcast or production, this fully-featured interface is kitted out with everything a modern creative could need.

With high-headroom mic preamps, onboard processing, an integrated loopback mixer and even built-in effects, you’ve got a wide range of future-proofed features, ready to spark your creativity and enhance your audio experience.

PreSonus Revelator io24 USB-C Audio Interface Key Features:

• Add Revelator power and flexibility to any XLR microphone
• 2 XMAX-L mic preamps with +48V phantom power for professional XLR mics and crystal-clear sound
• 2 stereo loopback streams for mixing audio from Zoom, Skype, backing tracks, and more
• Professionally crafted presets make you sound like a pro at the press of a button—or design, save, and share your own
• Stream Mix mode lets you create a complete stereo mix with Revelator io24 hardware inputs, effects, two channels of loopback audio, and reverb and send it to your streaming software.
• Over £1000 worth of software including Studio One Artist, Ableton Live Lite, and Studio Magic Suite.

PreSonus Professionalism

Flexible, professional and versatile – the Revelator io24 comes kitted out with a set of powerful PreSonus XMAX-L microphone preamps and onboard processing that make light work of both recording and streaming.

Complete with +48V phantom power, you’ve got everything you need to plug your favourite XLR microphone in and access crystal clear audio quality for your music production, podcast or live stream.

Intuitive Loopback Mixer

Boasting a powerful integrated loopback mixer, the Revelator io24 really sets itself apart from the competition with its ability to mix and record audio from entirely different software applications with your live audio.

Perfect for performing with backing tracks, recording skype/zoom calls and even adding sound effects and music to your live stream – PreSonus have made it quick and easy to achieve professional results.

Streaming Features

Designed with modern audio creatives in mind, the Revelator io24 features a Stream Mix mode which allows you to mix your inputs, loopback channels and effects, straight into your streaming software at the touch of a button.

Complete with a wide range of included software priced individually at over £1000, you’ve got everything you need to start recording, producing, streaming and podcasting straight out of the box.

PreSonus Revelator io24 USB-C Audio Interface Technical Specifications:

Audio Interface

• Type: USB-C Compatible USB 2.0
• Sample Rates: 44.1kHz, 48kHz, 88.2kHz, 96kHz
• Bit Depth: 24 bit
• ADC Converter Dynamic Range: 105 dB
• DAC Converter Dynamic Range: 105 dB
• Hardware Controls: Direct Monitor Balance, Main Output Level, Headphone Level, Mic Level, Mute, Preset Select, Return
• Software Controls: Mic Gain, Stereo Link, Loopback Mixes, Monitor Mix, Preset Management, Stream Mix Mode

Onboard DSP

• PreSonus StudioLive Fat Channel: High Pass Filter, Noise Gate / Expander, 3 Compressor models, 3 EQ models, and Limiter
• Digital Loopback Mixer: 8 input digital mixer, 3 stereo loopback mixes, stereo monitor mix
• Voice Effects: Doubler, Vocoder, Ring Modulator, Comb Filter, Detuner, Delay, Reverb

Microphone Inputs

• Maximum Level: +10 dBu (±0.5 dBu, min gain)
• Gain Range: 60 dB
• Frequency Response: 20 Hz – 20 kHz (+0.1dB/-0.3 dB, unity gain, unwtd)
• THD + N: 0.009% (1 kHz, -1 dBFS, min gain)
• EIN: -126 dBu (A-weighted, 150O, max gain)
• Input Impedance: 1.4 kO
• Phantom Power: +48 VDC (10 mA total)

Instrument Inputs

• Maximum Level: +10 dBu (min gain)
• Gain Range: 50 dB
• Frequency Response: 20 Hz – 20 kHz (+0.1dB/-0.3 dB, unity gain, unwtd)
• THD + N: 0.009% (1 kHz, min gain)
• Input Impedance: 1M O

Main Outputs

• Type: ¼” TRS, Female
• Maximum Level: +10 dBu (1 kHz, unity gain, z-balanced)
• Frequency Response: 20 Hz – 20 kHz (+0.1dB/-0.3 dB, unity gain, unwtd)
• THD + N: 0.003% ( 1 kHz, -1 dBFS, unity gain)

Headphone Outputs

• Maximum Power: 40 mW / channel @ 56O
• Frequency Response: 20 Hz – 20 kHz (+0.1dB/-0.5 dB, unity gain, unwtd)
• THD + N: 0.010 % (1 kHz, 0 dBFS, loaded)
• Impedance Working Range: 32O to 300O

Physical

• Height: 2.5”
• Width: 6.25”
• Depth: 6.25”
• Weight: 2lbs /1kg
