Shure MOTIV MVX2U Digital Audio Interface

Unlock a world of seamless recording and streaming with the Shure MVX2U Digital Audio Interface – a game-changing, single-channel XLR-to-USB adapter. Elevate your audio experience as you effortlessly connect any XLR microphone to your computer, revolutionizing your creative process.

Tailor your sound with ease through configurable DSP features and gain complete control via the ShurePlus MOTIV Desktop App. The MVX2U’s ingenuity extends to its future-proof design, ensuring it remains at the forefront of innovation through online firmware updates.

Equipped with up to 60dB of pristine gain, this XLR-to-USB adapter unleashes the full potential of your cherished dynamic microphones, including the iconic SM7B. Additionally, it offers up to 48V of phantom power, catering to condenser microphones and broadening your recording possibilities.

The MVX2U is the epitome of portability, elegance, and ruggedness. This compact interface seamlessly attaches directly to your XLR microphone or integrates smoothly into your setup using an XLR cable, adapting to your unique requirements. Embrace the future of audio connectivity with the MVX2U Digital Audio Interface.

Key Features:

• Make your favorite dynamic or condenser XLR microphone ready for podcasting or livestreaming with the MVX2U.
• The XLR-to-USB adapter enables digital recording and streaming right out of the box with Auto Level Mode and phantom power already switched on.
• Upgrade your XLR microphone with configurable onboard DSP via the ShurePlus MOTIV Desktop App.
• A built-in 3.5mm headphone jack with zero-latency monitoring ensures you’ll get the desired audio output every time.
• Supplies 48v of phantom power for condenser microphones.
• Provides clean gain of up to 60dB that is sufficient to amplify signals for dynamic microphones such as SM7B. CPortable form factor with a sleek yet robust build can be plugged straight onto an XLR microphone or used in-line with an XLR cable depending on your desired setup.
• Compatible with both Mac and Windows, connect your XLR microphone directly to your computer with the included 1m USB-C to USB-C cable

Shure MOTIV MVX2U Digital Audio Interface Specifications:

• Input: XLR
• Input impedance: 5.8kO
• Bit Depth: 16-bit/24-bit
• Sampling Rate: 48kHz
• Frequency Response: 20Hz to 20,000Hz
• Adjustable Gain Range: 0 to +60dB
• Maximum Input Level: 7dBV
• Power Requirements: Powered through USB-C
• Phantom Power: +48VDC
• Digital Noise Floor (20 Hz to 20 kHz, A-weighted): -117dBFS
• LED Indicator (Tricolour): Green = Ready, Amber = Error, Red = Mute
• Housing All Metal
• Net Weigh: 100 g (3.5 Oz.)
• Dimension: 44 x 140 x 158mm H x W x D
• Headphone Output: 3.5 mm (1/8 inch) 20 mW @ 32O
• Cable: 1M USB-C to USB-C cable

System Requirements

• USB: USB 2.0
• RAM: 64MB RAM (minimum)
• Operating System:
• MacOS 10.15 to 13
• 64 bit
• Minimum 2 GB of RAM
• Minimum 500 MB of hard disk space Windows 10
• 64 bit
• Minimum 2 GB of RAM
• Minimum 500 MB of hard disk space
