Solid State Logic Nucleus 2 Dark, DAW & Studio Controller

The perfect choice for music professionals in need of an intuitive and adaptable, central controlling device in a DAW-centric studio.

Your Audio Workspace Centre-Piece

Combining advanced multi-DAW hardware control, 2 fully-featured SSL SuperAnalogueTM mic pre’s, heavy-duty transport controls, monitor switching, talkback and a Dante audio interface in a single compact package, the Nucleus 2 DAW & Studio Controller is a unique proposition for project studio owners and music producers alike – Compatible with ProTools, Logic, Cubase/Nuendo and all major DAW applications

Solid State Logic Nucleus 2 Dark, DAW & Studio Controller Features:

• 16 Channel Project Studio Mixer
• Ethernet Connected DAW Controller
• Touch Sensitive 100mm Motorised Faders
• Switchable Simulatenous DAW Use
• LED’s & Self Illuminating Controls
• Heavy-Duty Transport Controls
• Premium-Grade Dante Audio Interface
• Digital Scribble Strips
• Benchmark SuperAnalogueTM Quality Output
• User-Customisable DAW & Key Command Mapping

The SSL Way

Created to provide users with that rugged hands-on approach that SSL have always delivered – free up your computer mouse and experience mixing as it should be, with extended functionality, responsive controls and detailed adjustments. Perfect for any application from music, to film to tv – the Nucleus 2 combined incredibly high audio with a streamlined workflow to help you focus on your sound.. not your screen!

DAW Control

Using technologies developed for SSL’s full-sized Matrix mixing console, the Nucleus 2 prides itself on its concise and compacted approach. Ideal for smaller studio spaces where a full-sized mixing desk is both unjustifiably large and expensive, the Nucleus 2 allows for similar functionality, using an innovative array of features designed to benefit the user experience.

With full compatibility for all major applications, connect up to 3 different DAWs simultaneously and conveniently switch between with a single button press. Transmit MIDI CC data and utilize dedicated and assignable hardware controls to easily control all major DAW and plug-in parameters – perfect for a smoother workflow experience when working on projects.

Simple, Yet Advanced Connectivity

To enable DAW control and Dante Audio, the Nucleus 2 connects to your computer via high-speed Ethernet connection. However, connect via a standard USB connection and your Nucleus 2 will perform as a regular keyboard, enabling key command emulation. Complete with a built-in USB hub, a standard jack footswitch connection and an SD card slot to store user-profiles – the Nucleus 2 is ready to meet your user-customizable needs.

SSL Native Plug-ins

Insistent on providing you with the full, world-renowned, Solid State Logic experience, they have generously included their SSL Native Essentials bundle with each Nucleus 2 purchase. These highly sought-after plug-ins feature an SSL Channel EQ, SSL Dynamics Channel and an SSL Stereo Bus Compressor.

Modelled on their classic analogue counterparts, these plugins are a welcome, high-quality addition to the Nucleus 2 experience, ensuring you have both the tools and the software to get the job done!

Solid State Logic Nucleus 2 Dark, DAW & Studio Controller Specifications:

• Excellent visual feedback via self illuminating buttons, LED’s and DAW Level Metering
• Compatible with ProTools, Logic, Cubase/Nuendo and all major DAW applications
• Switch between 3 connected DAW’s with a single button press
• Two banks of 8 channel controls plus centre section controls
• Touch sensitive 100mm motorised faders
• Ethernet connected DAW Controller for professional project studios
• Digital Scribble Strips with assignable V-Pots and soft keys
• Completely user customisable DAW & Key Command mapping
• Remote Logictivity Browser for effortless configuration
• SD card for non volatile project storage
• Large heavy duty transport buttons and high quality jog/shuttle wheel
• Digital S/PDIF I/O to the AD/DA of the audio interface
• Two headphone outputs and one iJack monitor input
• Standard 1/4″ Jack footswitch connection
• A unique audio nerve centre for your project studio
• Benchmark SuperAnalogueTM quality output to 2 stereo sets of +4dBu monitor outputs
• High quality Dante audio interface (44.1kHz – 96kHz, 24 Bit) over ethernet
• Zero latency Rec monitoring with wet/dry control to balance input and DAW playback
• Two Combi XLR mic/line/instrument level inputs to audio interface and monitor outputs
• Insert send/return connections switched between inputs and DAW playback for mixdown
• SSL SuperAnalogueTM Mic Pre’s, identical to those used on SSL Duality and AWS consoles
• Mic inputs have 80Hz High Pass Filters, Phase Reverse and Phantom Power
• Additional “external” SuperAnalogueTM input monitor path for another audio interface
• Three USB sockets for use as a 3 port USB hub
• Dual Ethernet ports for incorporating additional Dante devices into your studio
