Yamaha MG06X 6 Channel Mixing Desk With Effects

Yamaha MG06X 6 Channel Mixing Desk with Effects

The Yamaha MG06X is Yamaha’s most compact mixing desk of the new MG III range, an ideal choice for small duets or solo performers that don’t need the bells and whistles of a 24 channel desk on stage. As part of a portable audio system, the MG06X gets the job done with great results.

Whilst there may be cheaper small mixers on the market, under the hood Yamaha have packed in technology and quality that transcends its reasonable price tag.

The MG06X’s all-metal chassis gives it a presence and ruggedness for life on the road, whilst remaining lightweight (under 1kg!). Two Class A D-PRE microphone preamps deliver high headroom, low impedance, and clear full-range sound. +48v Phantom Power also allows the home producer or live engineer to connect more sensitive condenser microphones to the MG06, great for mixing low-level instruments on stage or studio vocal microphones.

2 band EQ, 3 reverb types and 3 delay types allow you to tweak the perfect atmosphere and room space for a studio recording or to add presence for a solo stage performance. A versatile output section features balanced XLR outputs and stereo 1/4″ jacks alongside a dedicated headphone output to give you uncompromising sound quality even at the highest volume levels in any application.

Specifications:

• 6 Channels
• Frequency Response 20 Hz – 20 kHz
• Mic Phantom Power   48 V
• Control Types Knobs
• Headphones output   Yes
• Meter Indicator  2 x LED level meters (7 segments)
• Features  Headphone output volume control
• Mic Channels  2 mono
• Mic Channels Connector   XLR / phone 6.3 mm
• Line Channels  4 mono / 2 stereo
• Line Channels Connector  Phone 6.3 mm
• 2-Band EQ
• Effects Qty  6
• Effects Type  Delay, plate, Room, Reverb
• Connections

– 2 x audio line-in / microphone ( XLR / phone 6.3 mm )
– top 2 x audio line-in ( phone mono 6.3 mm x 2 )
– top 1 x audio line-out ( phone mono 6.3 mm x 2 )
– top 1 x balanced audio output ( XLR x 2 )
– top 1 x headphones ( phone stereo 6.3 mm )

• Power

Max Power Consumption 12 W

Included Accessories

 Power adapter

Dimensions & Weight – W 14.9 cm   x  D 20.2 cm  x  H  6.2cm

Weight – 0.9kg
